MotorSolve - BLDC
Brushless DC and Permanent Magnet AC Motor Design Software

MotorSolve BLDC is the only motor and generator design software you need to get an accurate and complete prediction of your machine's performance. Our powerful automated finite element analysis engine is embedded inside, therefore no model exporting or additional software is required.
Overview

Performance cannot be predicted by general approximations and magnetic circuit calculations alone. MotorSolve BLDC performs accurate FEA-based machine simulations to:

  • Predict performance properly when there is saturation
  • Account for all loss sources, such as eddy current and hysteresis
MotorSolve BLDC flow chart
Our Features
We work hard every day to make life of our clients better and happier
  • Templates
    Synchronous Reluctance
    Interior Permanent Magnet
    Surface Mounted
    Bread-loaf
    Spoke
    Inset

    All standard slot types (square, round, slotless, parallel tooth, etc) are also included.

    Custom rotor and stator geometries can be imported.
  • Design Parameters
    Design Parameters
    • Geometric dimension of the magnets, teeth and slots
    • Number of poles and slots - can be arbitrarily large
    • Stack length
    • Lamination, coil and magnet material
    • Temperature for each component
    • Skew & skew prediction for zero cogging torque
  • Winding Layout

    • Coil winding layout: Select from a list of automatically calculated balanced layouts or specify via manual entry
    • Detailed end winding geometry
    • Supports several wire sizing methods
    • Relevant factors are automatically calculated
    • Winding charts available
      • Phase Back-EMF
      • Line-line Back-EMF
      • Back-EMF harmonics
      • Phase flux linkage
      • Winding factors
      • Görges diagram
      • Airgap MMF
      • Animated Airgap MMF


  • Motor Performance, Charts & Fields

    Output Waveforms and Charts
    • Current
    • Back-EMF
    • Torque
    • Flux Linkage
    • Phasor Diagram
    • And many more
    Performance Calculations
    • Torque
    • Efficiency
    • Air Gap Flux
    • Cogging Torque
    • Several Efficiency Maps for Motors & Generator (Torque, Loss, Power Factor, etc)
    • And many more

    Field Plots
    • Demagnetization prediction and effects based on irreversible model
    • Flux density
    • Hysteresis, eddy current, iron and total losses
    • Surface Force Density
    • And many more
    Drives
    Drives can be treated as either ideal or PWM, supporting both wye and delta connections.
  • Scripting
    Powerful scripting capability for customization, batching and optimization: All MotorSolve commands can be accessed through APIs. Use this feature with any programming language or ActiveX compliant software (e.g. Microsoft Excel).
    • Auto Sizing
      An initial value for several parameters related to the size of the machine based on:
      • torque per unit volume
      • rated current density
      • MotorSolve | Thermal Module
        MotorSolve Thermal is a 3D FEA-based thermal analysis tool for calculating the steady-state temperatures using the losses from BLDC's electromagnetic analysis and perform the electromagnetic analyses at these steady-state temperatures.

        • Report and Output

          • Design parameters, performance data and summary comparisons can be recorded in an experimental log or report (PDF)
          • Results are easily accessible either with the use of the clipboard or export functionality
          • The summary feature compares two or more designs side-by-side and highlights the differences in design data.
        • Export Options
          Simcenter Amesim VHDL-AMS
          FloMASTER           Simulink©
          MagNet           OPAL-RT eDRIVEsim
          DXF Data export (as table or chart)
        • Smart machine scaling
          A method for rapid system-level verification: the exported magnetic and thermal analysis results data can be scaled to correspond to a machine in which all mechanical dimensions have been scaled by the desired factor.
        Motor Analysis

        MotorSolve BLDC calculates machine performance based on automated finite element analysis simulations. There is no need to construct the model, perform mesh refinements and extensive post-processing to extract motor related results. MotorSolve performs these operations for the user.

        Using the template interface, a desired waveform, quantity or field is selected with the operating conditions specified.

        MotorSolve BLDC includes several analysis methods, suitable for different phases of the design process. The waveforms, fields and charts are computed using one of the selected analysis method, allowing users to choose the computation time based on their required degree of accuracy.

        ANALYSIS TYPES

        D-Q & Lumped Parameter Analysis
        • Ideal for what-if analysis: initial sizing or design variations
        • Rapid: based on a single FEA simulation to characterize the performance
        • The component values from the equivalent circuit of the D-Q approximation can also be obtained using the lumped parameter analysis

        PWM Analysis
        • Perform a dynamic simulation of the electronic commutation in a three-phase full-bridge
        • Squarewave or Sinewave
        • Important at high speeds: current waveforms differ significantly from the ideal
        • Also supports non-linear PWM analysis method

        Motion Analysis
        • Perform a full time-stepping non-linear FEA simulation
        • Wye or Delta
        • Sinusoidal or six-step drive
        • Highly accurate for all types of operating conditions and ideal for final design verification
        Generator Analysis

        MotorSolve BLDC also offers an optional generator analysis feature. The result waveforms and charts, applicable to both motors in generating mode and AC generators, can be computed with one of four different analysis types available.

        ANALYSIS TYPES

        Operating Points
        Generated a chart of the selected quantities related to the short-circuited and maximum power point of the generator. The results are calculated from the nonlinear D-Q model of the motor, obtained from a FEA solve of the currents between 0 and the short-circuit current.

        DQ Analysis
        • Ideal for what-if analysis: initial sizing or design variations
        • Rapid: based on a single FEA simulation to characterize the performance

        Reduced Order Model
        • Perform a dynamic simulation of the electronic commutation in a three-phase full-bridge
        • Squarewave or Sinewave
        • Important at high speeds: current waveforms differ significantly from the ideal
        • Also supports non-linear PWM analysis method

        Motion Analysis
        • Perform a full time-stepping non-linear FEA simulation to simulate a generator connected to resistive/inductive load
        • Wye or Delta
        • Sinusoidal or six-step drive
        • Highly accurate for all types of operating conditions and ideal for final design verification
